We are interested in the influence of light scattering of bacteria in the arsenic detection. In order to test that we had to purify the GFP from bacterias. We chose the Three-Phase Partitioning method [1] because that seemed to be an easy and interesting method to separate GFP from bacterias. We started the protocol in good conditions but at the step where we should have seen if the concentration of the starting buffer was good, the drops surprisingly seemed to go up in each concentration. We tested a lot of different concentrations, but we obtained each time the same results: the drop desperately went up. We didn’t discouraged and decided to continue with 3 different concentrations (1.6M, 3M and 4M of starting buffer). Finally, the results gave that the GFP was not visible to the naked eye but with fluorescence analysis the GFP was existing in the 3 samples. We were very happy of these results and concluded to perform again the experiment with more bacterias and with the 1.6 M starting buffer.


  • 1.6 M starting buffer composed of:
    • 10.57g of ammonium sulphate
    • 2.5 ml of 50nM of Tris Buffer pH 8
    • add water until 50ml
  • eGFP bacteria
  • Ars reporter control bacteria
  • tert-Butanol (ref: 19460)


  • Compare absorbance of eGFP bacteria and bacteria control (to see if we can put the same volume)
  • Take 50ml of eGFP bateria and 50ml of control bacteria
  • Centrifuge 2 tubes at 10 000 rpm(or the max on the bug centrifugeuse) during 10 min (to convert rpm in rcf RCF = 1.1118 x 10-5 x r x rpm^2)
  •  Remove supernatant, we only keep the pellet bacteria
  • Add 5ml of 1.6M of starting buffer and 5ml of t Butanol in the 2 tubes
  • Vigourous shaking during 1min (vortex)
  • Centrifuge during 10min at 1000rpm
  • Observe 3 phases: butanol, membrane and constituent cells, GFP phase for eGFP bacteria and without GFP for control.20150421_10331420150421_103322
  • Keep only the lowest phase, which is GFP phase for eGFP bacteria and without GFP for control and remove the rest
  • Add 500μL of t Butanol
  • Centrifuge 2 tubes at 2000rpm during 10min
  • We obtained again 3 same phases 20150421_110409
  • Keep only the lowest phase, which is GFP phase for eGFP bacteria and without GFP for control and remove the rest
  • Measure green fluorescence , excitation at 488nm



absorbance of eGFP bacteria: 1.96 OD
absorbance of control bacteria: 2 OD

so we can put the same volume (50ml) because the OD values are close enough

fluorescence result:

eGFP:                      45083

control bacteria:       873

1.6M starting buffer: 1


We measured the fluorescence of 1.6M starting buffer to compare the green fluorescence between bacteria with GFP, bacteria and sample without bacteria.
The fluorescence of control bacteria of 873 can be explained because lots of things fluoresce in green in biology. The difference between eGFP and control bacteria fluorescence is significant.
We obtained about 4ml of free GFP (from lysis of eGFP bacteria).

REFERENCE: [1] William W Ward of Brighter Ideas, Three-Phase Partitioning for Protein Prufification [pdf]
